Junction Backlit Square Adjustable Frameless High Brighness Panel Light 3000K~8000K
Product Features
• Built in driver panel, integrated design
• Punch stamp iron back plate, more econonical panel light, good quality at comptitve prices
• High luminous, more than 100lm/w
• Junction design, with adjustable and edgeless advantages, to be installed easliy.
• CCT: 3 Color (WW, WH, NW), 1 color (3000K-8000K)
• Isolated driver and non isloated driver , to match different customer's demand
Round Adjustable Framelss LED Panel Light
| Power Consumption | 9W 18W 24W 36W |
| Mount Type | Concealed |
| Shape | Square |
| Dimmension (D*H) | 90*90*20mm |
| Cut Out Size | 60-75mm |
| Work Voltage | AC85-265V / AC175-265V |
| Lamp Type | SMD2835 |
| Housing Materials | Punch Stamp Iron |
| Luminous Efficiency | 90~100lm/w |
| Diffusor Mateirals | PP |
| Frequency | 50/60Hz |
| LED Driver | Isolated / Non Isolated |
| Power Factor | >0.5 |
| Colour Rendering Index (CRI) | Ra>70 |
| Dimmable | Non-Dimmable |
| Warranty | 2 years |
Adjustable Frameless Panel Light Specification
| Shape | Watt | Driver | Luminous Efficiency | Size
(mm) | Cutout
(mm) | CCT | PCS/CTN | CTN Size
(cm) |
| Round | 9W | Isolated
85-265V | 90-100lm/w | ø90*20 | ø60-75 | 3000K-8000K | 100 | 56*44.5*22 |
| 18W | ø118*20 | ø60-100 | 3000K-8000K | 80 | 63*36*26 |
| 24W | ø170*20 | ø60-150 | 3000K-8000K | 40 | 44.5*36*36 |
| 36W | ø220*20 | ø60-200 | 3000K-8000K | 20 | 45*44.5*24 |
| Square | 9W | Isolated
85-265V | 90-100lm/w | 90*90*20 | 60-75 | 3000K-8000K | 100 | 56*44.5*22 |
| 18W | 120*120*20 | 60-100 | 3000K-8000K | 80 | 63*36*36 |
| 24W | 170*170*20 | 60-150 | 3000K-8000K | 40 | 44.5*36*36 |
| 36W | 225*225*20 | 60-200 | 3000K-8000K | 10 | 45*44.5*24 |
Lighting Applications
1. General room lighting in ceilings, suspended ceilings
2. Interior lighting such as bed room, class room, study room, super market, store, wareshouse
3. Coffered ceiling lighting
4. Cabinet lighting
5. Lobby lighting
6. Sculpture and statue illumination
Warnings
1. Cut off the power before installation
2. Can't be used as emergency light
3. To keep them away for the flammable objects.
4. The environment temperature of the lamp operation: -20Ċ to +60Ċ
5. Do not try to open this unit , to have the professional person to open it
6. Internal lighing only, can be used outside lighting
|
|
Square Built in Driver Free Cutout Edgeless LED Panels 3 Color and 1 Color Images
|
